RYB Three Phase Indicator Light

Description

SuRCLe 3P RYB indicator light for ACDB

• 3P indicators are compact, DIN mounted, long lasting indicator lamps designed for saving space and power in the ACDB boxes.
• Ideal for solar ACDB to show phase availability.
• Compact.
• Can be used for 3 independent phase-neutral supply — need not be 3P+N supply.  Example:
  • • • • • • • Red-Grid
              • Yellow: Genset
              •  Blue: Solar

Technical Data:

Rated Voltage (Un) :230V AC

Rated Frequency : 50/60 Hz

Rated Isolating voltage (Ui): 400V

Rated Impulse withstand Voltage(Uimp): 4kV

Number of phases: 3P

Light source: LED Diode

Colors: Red,  Yellow, Blue

Terminals: pillar type

Cable termination: 1.5~6mm2

Torque of screw: 1.2Nm

IP Degree: IP 20

Standards: IEC/EN 60947-5-1

Size : 40 x 29.5 x 17.5 mm

Weight: 71gm

1-year warranty.
